DECORATIVE SUSPENDED LED HIGH BAY WITH 16" REFLECTOR

Family of decorative suspended LED luminaires for general illumination in medium to high ceiling applications such as offices malls and retail spaces where long life and energy efficient LED operation is desirable.

Housing:

Extruded and anodized aluminum housing.

Reflector:

The prismatic frosted UV-stabilized 16″ reflector is a practical and aesthetic solution for public areas. The acrylic reflector produces a soft, diffused glow to put the right light in the area.

Mounting:

Junction box with a hook.

Information and Downloads

Document Title Download Email

Overview

  • ApplicationCommercial, Deco

  • MountingSuspended

  • Lamp Type / Light SourceLED

  • Size16"

  • ShapeRound

  • MaterialAluminum

  • Casting/Housing ColorSilver

  • DimmableYes

  • Wattage36.5 W, 57 W, 84 W

  • Voltage120-277 V, 347 V

  • Color Temperature2700K, 3000K, 3500K, 4000K

  • Lumen output range3 001-4 000, 4 001-6 000, 6 001-8 000

  • EnvironmentDamp

  • Product TypeHigh Bay

  • ReflectorFrosted acrylic
