SLG-5L
Plastic Battery Unit
The commercial SLG-5L features a plastic battery unit designed to provide an economical and versatile solution to emergency lighting needs within a small and compact design. The SLG-5L series is configured with two 5 W LED heads and can run for 90 minutes duration as a standalone unit.
- 120/347 VAC 60 Hz input, field selectable
- High efficiency, rapid recovery, precision control charging system
- Momentary push button test switch
- Diagnostic/pilot LED for AC ON and CHARGE
- Fully automatic, current limiter charger − Line latched, low voltage protection
- Brownout and short circuit protection
- Maintenance free, sealed lead acid battery
- White thermoplastic is standard
- CSA Certified to C22.2 141-15

Mounting
Wall mount
Lamp Type / Light Source
LED
Casting/Housing Color
White
Material
Plastic
Number of Lamps
2
Voltage
6 V
Wattage
5 W
