SLBNX

SLBNX

HAZARDOUS LOCATION BATTERY UNIT

The SLBNX series of battery units is designed to operate in the most extreme environments. The unit, designed using a polycarbonate housing, maintains its sealed interior with a continuous integral gasket. The SLBNX series is available in 6 VDC and 12 VDC versions in 36 W, 50 W, 72 W, 100 W or 130 W wattage capacity for a minimum of 30 minutes in emergency mode. Auto test feature is standard.

  • 120/277/347 VAC 60 Hz input, field selectable
  • High efficiency, rapid recovery, precision control charging system
  • Momentary push button test switch
  • Diagnostic/pilot LED for AC ON and CHARGE
  • Fully automatic, current limiter charger − Line latched, low voltage protection
  • Brownout and short circuit protection
  • Maintenance free, sealed lead acid battery
  • Black or white polycarbonate housing
  • Class I, div 2, groups A, B, C, D
  • Class II, div 2, groups F, G
  • Class III, div 2

Information and Downloads

Document Title Download Email

Overview

  • Quick shipNo

  • Lamp Type / Light SourceLED

  • Number of Lamps2

  • MaterialPolycarbonate

  • Casting/Housing ColorBlack, White

  • Wattage4 W, 5 W, 6 W, 7 W

  • Voltage12 V, 6 V

  • Lumen output range301-400 Im, 401-500, 501-600, 601-700

  • RatingsIP66, NSF, NEMA 4X, Class II Division 2, Class III, Class I Division 2

  • EnvironmentWet, Hazardous

  • Product TypeBattery Units

  • Output Voltage12V, 6V
