SLBIF

WEATHERPROOF NON-METALLIC BATTERY UNIT

The SLBIF series of NEMA4X and EEMAC4X rated weatherproof battery units is designed to operate in the most extreme environments. The fully gasketed, reinforced, non-metallic housing features a hinged cover that secures with durable screw locks. The SLBIF series is available in 6VDC, 12VDC and 24VDC versions in a range of wattage capacities between 36 and 720W, for 30 minutes duration.

  • 120/347 VAC or 277 VAC, 60Hz Input
  • High efficiency, rapid recovery, precision control charging system
  • Momentary push button test switch
  • Diagnostic/pilot LED for AC ON and CHARGE
  • Fully automatic, current limited charger − Line latched, low voltage protection
  • Brownout and short circuit protection
  • Maintenance free, sealed lead acid battery
  • Non-Metallic Housing, grey finish standard
  • CSA logo with C22.2 141-15

Information and Downloads

Document Title Download Email

Overview

  • Lamp Type / Light SourceLED, Quartz Halogen, Tungsten

  • MaterialPolycarbonate

  • RatingsNEMA 4X

  • Product TypeBattery Units
