SLA

STEEL BATTERY UNIT

The SLA series of commercial steel battery units is designed to provide efficient and reliable emergency lighting. Utilizing a sturdy, all steel housing, the SLA presents a modern and unobtrusive design. On higher capacity models, the cabinet front is sloped to allow better internal access and superior low angle light distribution.

The SLA can also accommodate a wide variety of options, including auto-testing self-diagnostics and remote testing.

  • Lamp heads include PAR18 small style and die cast metal MR16 type
  • 6VDC or 12VDC emergency power output versions (as specified)
  • Wattage capacities from 18 to 72W
  • 30 Minutes emergency power duration standard
  • 120/347 VAC 60 Hz input, field selectable
  • High efficiency, rapid recovery, precision control charging system
  • Momentary push button test switch
  • Diagnostic/pilot LED for AC ON and CHARGE
  • Fully automatic, current limited charger − Line latched, low voltage protection
  • Brownout and short circuit protection
  • Maintenance free, sealed lead acid battery
  • 20 Gage Steel White powder coat finish standard
  • CSA logo with C22.2 141-15

Information and Downloads

Document Title Download Email

Overview

  • Lamp Type / Light SourceLED, Quartz Halogen, Tungsten

  • MaterialSteel

  • Product TypeBattery Units
