Easy Out – SLA-1L/SLA-2L/SLA-3L/SLA12-2L

STEEL BATTERY UNIT

The commercial SLA-1L, SLA-2L, SLA-3L and SLA12-2L features a steel battery unit designed to provide efficient and reliable emergency lighting. Utilizing a sturdy all steel housing, our series presents a modern and unobtrusive design.

LED lamps have a limited lifetime warranty.

  • 120/347 VAC 60HZ input, field selectable
  • 1.9 W power consumption on AC input for LED exit portion of combination sign
  • LED Emergency DC wattages as follows: 6 VDC = 0.9 W; 12 VDC = 1.8 W
  • Momentary push button test switch
  • Pilot LED for AC ON and CHARGE
  • Fully automatic, current limited charger
  • Brownout and short circuit protection
  • Maintenance free, sealed lead acid battery
  • 20 Gauge Steel white powder coat finish
  • CSA Certified to C22.2 141-15
  • CSA Certified to C860-11

Information and Downloads

Document Title Download Email

Overview

  • Lamp Type / Light SourceLED

  • MaterialSteel

  • Product TypeBattery Units
