PRMQ

DIE CAST ALUMINUM RUNNING MAN COMBO

The commercial decorative die cast aluminum Running Man combo series is the perfect match of aesthetics and durability. Its unique new design provides spec-grade die cast running man signs with LED emergency lights in a low-profile frame and a spec-grade curved faceplate. The series has been designed with ultra-bright, energy efficient, long-lasting white LED lamps for the exit sign and ultra-bright white LED lamps in the emergency lighting heads. Faceplates have a quick-snap closure for ease of installation. Suitable for damp locations.

  • 120/347 VAC field selectable, or 277 VAC
  • 1.9 W power consumption on AC input for LED exit portion of combination sign
  • LED Emergency DC wattages as follows: 6 VDC = 0.9 W; 12 VDC = 1.8 W
  • Momentary push button test switch
  • Pilot LED for AC ON and CHARGE
  • Fully automatic, current limited charger
  • Brownout and short circuit protection
  • Maintenance free, sealed lead acid battery
  • Extruded Aluminum in white powder coat finish standard, other finishes and colours optional
  • CSA Certified to C22.2 141-15
  • CSA Certified to C860-11

Information and Downloads

Document Title Download Email

Overview

  • Lamp Type / Light SourceLED

  • MaterialDie cast aluminum

  • Product TypeCombos

  • Legend TypeRunning Man
