L1LEH GEN. 2
ECONOMICAL AND HIGH-PERFORMING LED LINEAR HIGH BAY LUMINAIRE WITH 3 CCT AND 3 POWER SELECTABLE FEATURES
Stanpro’s economic L1LEH Linear High Bay with integrated receptacle for smart and non-smart sensors, is ideally suited for high ceiling warehouses as well as arenas where uniform and efficient lighting is required.
This luminaire meets BC Hydro requirements, thus providing considerable utility rebates in British Columbia.
Application
Industrial,
Commercial
Casting/Housing Color
White
Color Temperature
3 500/4 000/5 000 K
CRI
80
Dimmable
Yes
Dimming
0-10V
Environment
Damp
Lamp Type / Light Source
LED
Lens Type
Frosted polycarbonate
Light Distribution
Medium
Lumen Output Range
12 800 - 100 000
Material
Steel
Mounting
Surface,
Suspended,
Conduit mount,
V-Hook,
Aviation Cable
Quick Ship
Yes
Shape
Linear
Size
48",
24"
Voltage
120-347 V
Wattage
80-625 W
Applications
