CDHB2 - HAZARDOUS LOCATION HIGH BAYS
CLASS I, DIVISION 2, GROUPS A, B, C, D
The CDHB2 LED high bays are specifically engineered for use in hazardous environments containing flammable vapors or gases. This series is designed for locations prone to vibrations, as well as NEMA 4X environments characterized by exposure to wind, water, snow, or high ambient temperatures.
Application
Industrial,
Commercial,
Hazardous
Casting/Housing Color
Grey
Color Temperature
4000K,
5000K,
3000K,
2700K,
5700K,
6500K
Dimmable
Yes
Environment
Wet
Lamp Type / Light Source
LED
Lumen Output Range
4 001-6 000,
8 001-10 000,
14 001-16 000,
18 001-24 000
Material
Die cast aluminum
Mounting
Surface,
Ceiling mount,
Wall mount,
Pole mount,
Pendant
Product Type
High Bay
Ratings
Class I Division 2,
IP66,
NEMA 4X
Voltage
120-277 V,
277-480 V
Wattage
100 W,
150 W,
60 W,
30 W
