T5 Type B
Ballast Bypass Led Tube
Replace 28/54W traditional using only 13/25W LEDs double-ended glass tubes - Perfect for long term and safety installation.
Perfect for long term installation; no need to go back and replace the ballast at a later time thus reducing maintenance costs. Type B lamps offer the best system efficiency; no additional power consumption is drawn from the ballast. The double-ended technology can operate with shunted and non-shunted sockets.
Shape
T5
Wattage
13 W,
25 W
Voltage
120-347 V,
120-277 VAC
Color Temperature
4000K,
5000K,
3500K
Environment
Damp
Base
G5
CRI
82,
83
Brand
Standard
Installation Method
Ballast Bypass
Lumens (Lm)
1 600,
1 700,
1 650,
3 500
Maximum Overall Length MOL
1168.4 mm (46 in)
Safety Coating
No
Applications
