RMRNX

HAZARDOUS LOCATION RUNNING MAN

The RMRNX series for hazardous locations running man is designed to operate in extreme environments. The unit, designed using a polycarbonate housing, maintains its sealed interior with a continuous integral gasket. As well, LED pilot light and test switch are sealed type. Available in AC/DC and internally self-powered versions.



  • LED ultra bright light source
  • 120/277/347 VAC 60Hz Input, field selectable
  • 1.9 W power consumption single or double face
  • Emergency DC wattages as follows: 6 VDC = 0.9 W, 12 VDC = 0.9 W, 24 VDC = 0.9 W
  • Reinforced polycarbonate
  • Universal faces – Universal mounting : ceiling mount, wall mount, end mount
  • Class I, div 2, groups A, B, C, D
  • Class II, div 2, groups F, G
  • Class III, div 2

Information and Downloads

Document Title Download Email

Overview

  • Quick shipNo

  • MountingUniversal

  • Lamp Type / Light SourceLED

  • MaterialPolycarbonate

  • Casting/Housing ColorBlack, White

  • Voltage120-277/347 V

  • RatingsIP66, NSF, NEMA 4X, Class II Division 2, Class III, Class I Division 2

  • EnvironmentWet, Hazardous

  • Legend TypeRunning Man
