Orbit – RLR
Adjustable Multi-spot Downlight
The Orbit RLR series is our LED recessed multi-spot. Whether you're designing a completely new commercial venue or planning a renovation, the Orbit RLR offers the flexibility for either of those options with the same housing. This is the ideal fixture for commercial office, residential, retail, restaurant and hotel lighting projects that require the beauty of recessed lighting.
Material:
Die cast aluminum. Optical compartment and metal back box.
Installation:
Integral wire connection box. Integral transformer for T-bar & drywall ceiling available.
Housing:
Non-IC new construction or existing ceiling.


Lamp Type / Light Source
LED
Size
Multi-spot
Shape
Square
Housing Type
Non-IC
Voltage
120 V,
347 V
Color Temperature
4000K,
3000K,
2700K,
3500K
Lumen Output Range
3 001-4 000,
4 001-6 000,
6 001-8 000,
8 001-10 000,
10 001-12 000,
12 001-14 000,
14 001-16 000,
16 001-18 000,
18 001-24 000,
2 001-3 000
Environment
Dry
Dimming
0-10V
Trim Color
White,
Black,
Silver
Baffle Color
White,
Black
