SLMC

VANDAL RESISTANT STEEL & LEXAN BATTERY UNIT

The SLMC series of vandal resistant battery units is designed to withstand intentional abuse and tampering. The lamp assemblies are completely shielded within a pair of heavy-duty, single piece, molded Lexan cubes. The durable, all steel cabinet utilizes a wrap-around cover plate for added protection and strength.

Units can be fitted with a wide range of lamp head types and options, including auto-testing self-diagnostics and remote testing.

  • Up to two lamp assemblies per cube available in either PAR18 small style or MR16 lamp
  • 6VDC, 12VDC or 24VDC emergency power output versions (as specified)
  • Wattage capacities from 36 to 320W
  • 30 minutes emergency power duration standard
  • 120/347 VAC 60 Hz input, field selectable
  • High efficiency, rapid recovery, precision control charging system
  • Momentary push button test switch
  • Diagnostic/pilot LED for AC ON and CHARGE
  • Fully automatic, current limited charger − Line latched, low voltage protection
  • Brownout and short circuit protection
  • Maintenance free, sealed lead acid battery
  • White thermoplastic is standard
  • CSA logo meets C22.2 141-15

Information and Downloads

Document Title Download Email

Overview

  • Lamp Type / Light SourceLED, Quartz Halogen, Tungsten

  • MaterialSteel

  • Product TypeBattery Units
